Unicontrol M2430CL1-E Refrigerant Coil Module 2.0-2.5 Ton M2430 E

Product Description

The Unicontrol M2430CL1-E is a refrigerant coil module designed for air handlers, suitable for residential and light commercial applications. This model offers versatile usage options, including cooling and heat pump capabilities. It features a compact design for easy installation, even in tight spaces.

• Modular construction for multiple configurations.
• Uses energy-efficient R410A refrigerant.
• Compatible with various air handlers for optimized performance.

Product Highlights

The modular design and efficient operation make this refrigerant coil module a preferred choice for HVAC professionals.

Product Information

Standard Information

• Brand: Unicontrol
• Model Series: M-Series

Technical Specifications

• Nominal Capacity: 2.0-2.5 ton (9 kW)
• Air Flow Range: 200 to 700 CFM
• Coil Type: Refrigerant
• Refrigerant Type: R-410A
• Installation Orientation: Horizontal, Vertical Upflow
• Tonnage: 2.0-Ton, 2.5-Ton
• Configuration: H-Coil 6-Rows; Horizontal/Vertical Upflow
• Metering Device: TXV (R410A)
• Efficiency: 12 SEER
