Ubiquiti UVC-G5-PTZ G5 PTZ

Product Description

The Ubiquiti UVC-G5-PTZ is a compact, all-weather camera with ultra-low latency pan-tilt-zoom control and versatile mounting options. Motorized optical zoom delivers wide-area coverage and detailed close-ups without quality loss. Features include 2K resolution, 2x optical zoom, and IR night vision up to 20m (65 ft).

• Compact, all-weather camera
• Ultra-low latency pan-tilt-zoom control
• Versatile mounting options
• Motorized optical zoom delivers wide-area coverage and detailed close-ups without quality loss.

Product Highlights

This PTZ camera is ideal for comprehensive surveillance, offering smart detections for people, vehicles, and animals, and is designed for both indoor and outdoor use.

Product Information

Standard Information

• Brand: UBIQUITI
• Manufacturer Part Number: UVC-G5-PTZ

Technical Specifications

• Color: Black
• IR Night Vision: 20 m (65 ft)
• Zoom Mode: 2x Optical
• Smart Detections (People, Vehicles, Animals): ✓
• Resolution: 2K
• Field of View Wide: H: 99.7°, V: 51.9°, D: 121°
• Field of View Tele: H: 45.5°, V: 25.4°, D: 52.4°
• Pan-Tilt Range Pan: 350°
• Pan-Tilt Range Tilt: 100°
• Audio: Microphone
• Weatherproofing: IP66
• Tamper Resistance: IK04
• Mounting: Wall mount, pole mount (Included) Conduit adapter, surface, in-ceiling, pendant, corner mount (Optional)
• Networking Interface: 10/100 MbE RJ45 port
• Video Max. Frame Rate: 30 FPS
• Video Resolution: 4MP 2688 x 1512 (16:9)
• Optics Sensor: 5MP 1/2.7" CMOS
• Optics Lens: F 3.42–6.85 mm; ƒ/1.85–ƒ/2.4
• Night Mode: Built-in IR & white LED illumination with IR cut filter
• Max. Power Consumption: 14W
• Supported Voltage Range: 37—57V DC
• Power Method: PoE+
• Pole Mount Diameter: 1.5–2" (38–50 mm)
• Enclosure Material: Aluminum alloy, polycarbonate
• Mount Material Wall mount: polycarbonate
• Mount Material Pole mount: aluminum alloy
• Button: (1) Factory reset
• Ambient Operating Temperature: -30 to 45º C (-22 to 113º F)
• Ambient Operating Humidity: 0 to 90% noncondensing
• NDAA Compliant: ✓
• Certifications: CE, FCC, IC
• Power Source: PoE
• Mounting Type: Wall Mount
• Special Features: PTZ Technology
• Included Components: Wall, pole mount
• Indoor/Outdoor: Outdoor, Indoor
• Camera Mount: Wall Mount, Pole Mount
• Camera Style: PTZ
• View Angle: 121° Diagonal, 51.9° Vertical, 99.7° Horizontal
• Sensor: CMOS
• Night Vision: Yes
• IR Illumination Range: Up to 65.00 ft. (19.81 m)
• Maximum Resolution: 2688 x 1512
• Built-in Microphone: Yes
• Cable Type: Ethernet
• Power Supply: Power Over Ethernet (PoE)
• Design: IP66
