Ubiquiti UVC-DOORBELL-LITE-B UniFi Video Camera Doorbell Lite 5MP

Product Description

The UBIQUITI UVC-DOORBELL-LITE-B is a compact PoE video doorbell with two-way audio and versatile mounting options. It features a 5MP camera with a resolution of 1920 x 2560 (3:4) and an expansive field of view. Designed for outdoor use, it offers reliable performance and seamless integration with your security system.

• Compact PoE video doorbell
• Two-way audio
• Versatile mounting options

Product Highlights

This compact video doorbell offers two-way audio and versatile mounting.

Product Information

Standard Information

• Brand: UBIQUITI
• Manufacturer Part Number: UVC-DOORBELL-LITE-B
• Country of Origin: United States

Technical Specifications

• Dimensions: 137 x 40 x 26.4 mm (5.4 x 1.6 x 1")
• IR Night Vision: 5 m (16 ft)
• Resolution: 5MP 1920 x 2560
• Field of View: H: 95.8, V: 131.2, D: 175.9
• Audio: Two-way audio
• Weatherproofing: IPX5
• Mounting: Wall, 20 wedge (Included) Gang box, junction box (Optional)
• UniFi Application Suite: Protect
• Networking Interface: 10/100 MbE port
• Video Image Settings: Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
• Max. Frame Rate: 24 FPS
• Optics Sensor: 1/2.7" 5MP
• Lens: Fixed focal length
• Night Mode: Built-in IR LED illumination and IR cut filter
• Max. Power Consumption: 8W
• Supported Voltage Range: 37 57V DC
• Power Method: PoE
• Processor: Dual-core Arm Cortex-A7 based chip
• Weight Device: 142 g (5 oz) With flat wall mount: 165 g (5.8 oz) With 20 wedge mount: 179 g (6.3 oz)
• Enclosure Material: Polycarbonate, metal
• Mount Material: Formed sheet metal
• Button: (1) Ring button (1) Factory-reset
• Ambient Operating Temperature: -30 to 50 C (-22 to 122 F)
• Ambient Operating Humidity: 20 to 90% noncondensing
• Certifications: CE, FCC, IC
• Type: Video Doorbell
• Power Source: PoE
• Voltage: 37 - 57V DC
• Model: UVC-Doorbell-B
• Connectivity: Wired
• MPN: UVC-Doorbell-B
• Features: Weatherproofing IPX5
• Suitable For: Home
• Power: 8 W
• Subcategory: Doorbell, Wired Cameras (IP)
• Camera Security: Camera Security
• Series: Doorbells
• Storage: External DVR/NVR
• Cameras Included: 1
• Indoor/Outdoor: Outdoor
• Camera Mount: Wall Mount
• Camera Style: Fixed
• View Angle: 131.2 Vertical, 175.9 Diagonal, 95.8 Horizontal
• Sensor: CMOS
• Night Vision: Yes
• Maximum Resolution: 1920 x 2560
• Camera Audio: 2-Way Audio
• Built-in Microphone: Yes
• Output: Built-In Speaker
• Power Supply: Power Over Ethernet (PoE)
• Design: IPX5
• Width: 1.60 in. (40.64 mm)
• Depth: 1.00 in. (25.40 mm)
• Height: 5.40 in. (137.16 mm)
• What's in the Box: Camera, Mounting Hardware
