U.S. Motors XS12CA2JCR General Purpose Single Phase TEFC C-Face Motor

Product Description

The U.S. Motors XS12CA2JCR is a standard single-phase TEFC C-face motor designed for general purpose applications. It is ideal for various tasks in commercial and industrial settings. This motor provides reliable operation with a power output of one-half horse power and a rotational speed of one thousand eight hundred RPM.

• Single-phase power supply
• TEFC (Totally Enclosed Fan Cooled) enclosure for durability
• Designed for continuous duty operation

Product Highlights

The XS12CA2JCR motor is versatile, suitable for tasks requiring dependable power and efficiency.

Product Information

Standard Information

• Part Number: XS12CA2JCR
• Brand: U.S. Motors

Technical Specifications

• HP: 1/2
• RPM: 1800
• Enclosure: TEFC
• Service Factor: 1
• Frame Size: 56C
• Voltage Rating: 115/208-230
• Amperage: 9.8/4.9-4.9
• Mounting Type: C-Face - Less Base
• Weight: 32 lbs
• Full Load Efficiency: 62.9%
• Insulation Class: B
• Poles: 4
