U.S. Motors X30P2B Explosion Proof Three Phase TEFC Horizontal - Footed Motor

Product Description

The U.S. Motors X30P2B is an explosion-proof, three-phase TEFC horizontal footed motor designed for reliability in hazardous environments. This motor operates at thirty horsepower and features a maximum speed of 1800 revolutions per minute. It is suitable for industrial applications where safety and efficiency are essential.

• Explosion-proof motor for safety in hazardous environments.
• Powerful 30 hp output with three-phase capability.
• TEFC design for protection against dust and moisture.

Product Highlights

The X30P2B is ideal for various industrial uses, particularly in environments requiring explosion-proof solutions. Its robust construction ensures continuous operation and efficiency.

Product Information

Standard Information

• Brand: U.S. Motors
• Voltage Rating: 230/460

Technical Specifications

• Full Load Efficiency: 93.6%
• C Dimension: 27 inches
• Full Load Amps: 69/34
• Mounting: Horizontal - Footed
• Service Factor: 1
• Enclosure: TEFC
• Frame: 286T
• Weight: 433.0 lbs
• Insulation Class: F
• Full Load rpm: 1775 rpm
• Duty: Continuous Duty
• Phase: Three Phase
• Poles: 4
