U.S. Motors X2P2B Explosion Proof Three Phase TEFC Horizontal - Footed Motor

Product Description

The U.S. Motors X2P2B is an explosion proof three phase TEFC horizontal footed motor designed for demanding applications. This motor operates at two horsepower and offers a full load speed of one thousand eight hundred rpm. With a voltage rating of two hundred thirty to four hundred sixty volts and a frequency of sixty hertz, it is suitable for a variety of industrial tasks, especially in hazardous environments.

• Robust construction with cast iron frame
• Effective thermal management with TEFC enclosure
• Designed for continuous duty operation

Product Highlights

This motor is ideal for applications requiring reliable performance in explosion-prone areas. The three-phase design ensures consistent output across various operating conditions.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: X2P2B

Technical Specifications

• Duty: Continuous Duty
• Frame Material: Cast Iron
• Phase: Three Phase
• Insulation: F
• Enclosure Designation: TEFC - Totally Enclosed Fan Cooled
• Poles: 4
• Frame: 145T
• Full Load RPM: 1745 rpm
• Full Load Efficiency: 86.5%
• Mounting: Horizontal - Footed
• Voltage Rating: 230/460
• Motor Application: Explosion Proof
• Hz: 60 Hz
• Enclosure: TEFC
• Full Load Amps: 5.2/2.6
• Weight: 80.0 LB
• EAN or UPC: 786382089979
