U.S. Motors UN32S4CKR General Purpose Three Phase TENV Horizontal - Footless Motor

Product Description

The U.S. Motors UN32S4CKR is a general-purpose three-phase motor designed for various applications. This motor features a footless design suited for horizontal mounting, allowing flexibility in installation.

• 1.5 horsepower with a speed of 900 RPM
• Ideal for continuous duty applications
• Rated for 460 volts with a TENV enclosure

Product Highlights

This motor is efficient and reliable for industrial use, meeting the needs of HVAC systems, pumps, and fans.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: UN32S4CKR

Technical Specifications

• Full Load Amps: 3.8
• Poles: 8
• Hz: 60
• Motor Application: General Purpose, Unimount
• Duty: Continuous Duty
• Frame: 184, 184TCH
• Design: B
• Mounting: Horizontal Mount, Horizontal - Footless
• C Dimension: 16.8 inches
• Phase: Three Phase
• HP: 1.5
• Full Load rpm: 860
• Drive End Bearing: 6311-J/C3
• Full Load Efficiency: 72%
• Voltage Rating: 460
• Service Factor: 1.25
• Open End Bearing: 6211-J/C3
• RPM: 900
• Enclosure Designation: TENV - Totally Enclosed Non-Ventilated
• Enclosure: Totally Enclosed, TENV
• Insulation: F
• Weight: 70.0 LB
• EAN or UPC: 786382074517
