U.S. Motors UJ1P2GP Close Coupled Pump Motor Three Phase TEFC Horizontal - Footed Motor

Product Description

The U.S. Motors UJ1P2GP is a close coupled pump motor designed for reliable performance in various applications. This three-phase motor operates at one horsepower and reaches speeds of one thousand eight hundred rpm, suitable for continuous duty operations.

• One horsepower, three-phase motor
• TEFC enclosure for enhanced protection
• Designed for horizontal footed mounting

Product Highlights

The UJ1P2GP motor is engineered for pumping applications, offering robust efficiency and durability.

Product Information

Standard Information

• Brand: U.S. Motors
• Part #: 110672150

Technical Specifications

• Motor Application: Pump Motor
• Full Load Efficiency: 85.5%
• Duty: Continuous Duty
• Service Factor: 1.25
• Insulation: F
• Enclosure: TEFC
• C Dimension: 17.3 inches
• Phase: Three Phase
• Poles: 4
• Full Load rpm: 1740 rpm
• Mounting: Horizontal - Footed
• RPM: 1800 rpm
• Full Load Amps: 1.1
• Voltage Rating: 575
• Frame: 143JP
• Hz: 60 Hz
• Weight: 30.0 lb
• EAN or UPC: 786382106119
