U.S. Motors U32P3GC General Purpose Three Phase TEFC Horizontal - Footed Motor

Product Description

The U.S. Motors U32P3GC is a general-purpose three-phase motor designed for various applications. This motor operates at one and a half horsepower and runs at a speed of twelve hundred RPM. It features a total enclosed fan cooled (TEFC) design suitable for horizontal footed mounting. The motor is rated for a voltage of five hundred seventy-five and is ideal for industrial equipment such as pumps, compressors, and fans.

• Power: 1.5 HP
• Speed: 1200 RPM
• Mounting: Horizontal - Footed

Product Highlights

This general-purpose motor offers continuous duty performance with an efficiency rating of eighty-seven point five percent.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: U32P3GC

Technical Specifications

• Frame Size: 182TC
• Phase: Three Phase
• Full Load Amps: 1.8
• C Dimension: 16.1 inches
• Insulation Class: F
• Service Factor: 1.25
• Enclosure Type: TEFC
• Weight: 60 lbs
