U.S. Motors U25P1DCR General Purpose Three Phase TEFC Horizontal - Footless Motor

Product Description

The U.S. Motors U25P1DCR is a general-purpose motor designed for various industrial applications. This three-phase, totally enclosed fan cooled motor operates at twenty-five horsepower and is rated for three thousand six hundred RPM. The motor supports a voltage range of two hundred eight to two hundred thirty/ four hundred sixty and one hundred ninety to three hundred eighty volts. Its footless horizontal mount allows for flexible installation in diverse environments.

• Continuous duty operation
• High efficiency rating of 91.7%
• Serves applications such as fans, compressors, and pumps

Product Highlights

This motor's robust design makes it suitable for demanding industrial settings and enhances reliability under load.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: U25P1DCR

Technical Specifications

• RPM: 3600 rpm
• Phase: Three Phase
• Full Load Efficiency: 91.7%
• Duty: Continuous Duty
• Service Factor: 1.25
• Insulation Class: F
• Enclosure: TEFC
• Full Load Amps: 65-57/28.4
• Hz: 50/60 Hz
• Voltage Rating: 208-230/460 & 190/380
• Frame: 284TC
• Weight: 280.0 LB
• C Dimension: 28.2 in
• EAN or UPC: 786382104276
