U.S. Motors HD2P1H Hostile Duty Three Phase TEFC Horizontal - Footed Motor

Product Description

The U.S. Motors HD2P1H is a three-phase, TEFC (Totally Enclosed Fan Cooled) horizontal footed motor designed for hostile duty applications. This motor operates at two horsepower and has a speed of three thousand six hundred RPM. With a voltage rating of two hundred to two hundred eight volts, it is built for usage in rugged environments typical in industries like pulp and paper, sawmills, and chemical processing.

• Designed for continuous duty.
• Robust cast iron frame.
• Offers an efficiency rating of eighty-five point five percent.

Product Highlights

The HD2P1H model is ideal for environments requiring reliable motor performance under harsh conditions. Its three-phase motor structure helps in ensuring smooth operation in various settings.

Product Information

Standard Information

• Brand: U.S. Motors
• Part Number: HD2P1H

Technical Specifications

• Frame Size: 145T
• Poles: 2
• Voltage Rating: 200-208V
• Full Load Amps: 5.7/5.6
• Enclosure Type: TEFC
• Duty Type: Continuous Duty
• Insulation Class: F
• Service Factor: 1.15
• Full Load Efficiency: 85.5%
