U.S. Motors FD13SM2DZYR General Purpose Three Phase TEFC N-Flange Motor

Product Description

The U.S. Motors FD13SM2DZYR is a general purpose, three-phase motor designed for efficiency and reliability. This motor features a totally enclosed fan cooled (TEFC) enclosure which protects the internal components from dust and moisture. Its N-flange mounting allows for versatile installations in various settings.

• Electrical Type: Three Phase
• Power: 1/3 HP
• RPM: 1800

Product Highlights

This motor is suitable for applications requiring robust performance with consistent duty cycles. It operates at both 50 Hz and 60 Hz, providing flexibility in usage.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: FD13SM2DZYR

Technical Specifications

• Enclosure: TEFC
• Poles: 4
• Frame: 56Y
• Full Load RPM: 1800, 1425, 1725
• Hz: 50/60
• Insulation: F
• Voltage Rating: 190/380 & 208-230/460
• Full Load Amps: 2/1 & 1.8-2/1
• Torque Rating: Continuous Duty
