U.S. Motors FD12SA2D General Purpose Three Phase TEAO Rigid Motor

Product Description

The U.S. Motors FD12SA2D is a general-purpose three-phase motor designed for a variety of applications. This motor operates at half a horsepower and features a speed of one thousand eight hundred revolutions per minute. It is suitable for both fifty and sixty hertz electric systems. The motor supports dual voltage ratings of two hundred eight to two hundred thirty and four hundred sixty volts, making it versatile for different setups.

• 1/2 HP power rating
• 1800 RPM speed
• TEAO enclosure type (Totally Enclosed Air Over)

Product Highlights

The FD12SA2D motor is built with a rigid mount for stability during operation. Its automatic reset thermal protection ensures safety during usage. The motor is classified as continuous duty, suitable for long-term applications without overheating.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: FD12SA2D

Technical Specifications

• Poles: 4
• Mounting: Rigid
• Voltage Rating: 208-230/460
• Duty: Continuous Duty
• Enclosure Designation: TEAO - Totally Enclosed Air Over
• Thermal Protection: Automatic Reset
• Motor Application: General Purpose
• Hz: 50/60 Hz
• Frame: 56H
• C Dimension: 10.8 in
• Full Load Efficiency: 80 %
• Full Load RPM: 1425 rpm, 1725 rpm
• Service Factor: 1.15
• Weight: 16.7 LB
• EAN or UPC: 786382088453
