U.S. Motors FD12BA2P9 General Purpose Single Phase TEAO Resilient Base Motor

Product Description

The U.S. Motors FD12BA2P9 is a general-purpose single-phase motor suitable for various applications. It has a power rating of one-half horsepower and operates at 1800 RPM, making it a reliable motor for general and farm duty applications.

• Single-phase operation ensures compatibility with typical residential and commercial power sources.
• TEAO (Totally Enclosed Air Over) enclosure provides protection from dust and moisture, extending the motor's life.
• Resilient base mounting ensures stability and reduces vibration during operation.

Product Highlights

This motor is designed for continuous duty and is ideal for agricultural and general-purpose applications. It can operate at both 115 and 230 voltage ratings, providing flexibility for different electrical systems.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: FD12BA2P9

Technical Specifications

• HP: 1/2
• Duty: Continuous Duty
• Frame: 56
• Voltage Rating: 115/230
• Full Load Amps: 5.4/2.7
• RPM: 1800
• Hz: 60
• Insulation: Class B
• Service Factor: 1.25
• C Dimension: 12.3 inches
• Weight: 24.0 lbs
• Enclosure: TEAO
