U.S. Motors EH741 Definite Purpose Three Phase ODP C-Face Motor

Product Description

The U.S. Motors EH741 is a definite purpose three phase open drip proof motor. It offers a power rating of three horsepower and runs at a speed of three thousand six hundred RPM. This motor is designed for various applications requiring reliable performance.

• Three-phase power for efficient operation
• C-Face mounting allows for versatile installation
• Open drip proof design for use in various environments

Product Highlights

This motor is ideal for pump applications and supports different voltage ratings between two hundred eight to four hundred sixty volts.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: EH741

Technical Specifications

• Frame: 56C, 56J
• Enclosure Designation: ODP - Open Drip Proof
• Full Load RPM: 2850 RPM, 3450 RPM
• Service Factor: 1.21
• Full Load Amps: 8.28
• Frequency: 60 Hz, 50/60 Hz
• Voltage Rating: 208-230/460, 460, 230, 208
• Motor Application: Pump Motor, Definite Purpose
• Drive End Bearing: BALL
• Phase: Three Phase
• Mounting: C-Face - Less Base, C-Face
• HP: 3
• Poles: 2
• Insulation: B
• C Dimension: 13.1 inches
• Rated Duty: Continuous Duty
• Weight: 40.0 LB
• EAN or UPC: 786382074395
