U.S. Motors EH740 Definite Purpose Three Phase ODP C-Face Motor

Product Description

The U.S. Motors EH740 is a definite purpose three phase ODP C-face motor designed for reliable operation in various applications. This motor operates efficiently at three horsepower and a rotational speed of three thousand six hundred RPM. It features a C-face mount for easy installation and is built with an ODP enclosure, making it suitable for environments where exposure to moisture is a concern.

• Three phase motor with a power rating of 3 HP
• Voltage rating of 208-230/460 V
• Continuous duty operation

Product Highlights

The U.S. Motors EH740 is ideal for pump applications, providing robust performance and high efficiency.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: EH740

Technical Specifications

• Motor Application: Pump Motor, Definite Purpose
• Service Factor: 1.21
• Mounting: C-Face - Less Base
• Voltage Rating: 208-230/460
• Frequency: 60 Hz, 50/60 Hz
• Phase: Three Phase
• Duty: Continuous Duty
• Insulation Class: B
• Weight: 41.0 LB
• Full Load Amps: 8.28
• RPM: 3600
