U.S. Motors EH617 Definite Purpose Three Phase ODP C-Face Motor

Product Description

The U.S. Motors EH617 is a reliable definite purpose three-phase ODP C-face motor designed for various applications, including pump operations. This motor features a power rating of one and a half horsepower and operates at a speed of three thousand six hundred rpm. It supports a voltage rating of two hundred eight to two hundred thirty or four hundred sixty volts.

• Type: Three Phase
• Power: 1.5 hp
• Frame Size: 56J

Product Highlights

Ideal for demanding pump applications, this motor ensures smooth operation and efficiency. Its open drip proof design makes it suitable for various environments.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: EH617

Technical Specifications

• Motor Application: Pump Motor, Definite Purpose
• Frame: 56C, 56J
• Mounting: C-Face - Less Base, C-Face
• Hz: 60 Hz, 50/60 Hz
• Voltage Rating: 208-230/460
• Full Load Amps: 3.96
• Insulation Class: B
• RPM: 3600
• Poles: 2
• C Dimension: 11.6 in
• Service Factor: 1.3
• Enclosure: ODP - Open Drip Proof
• Weight: 27.0 LB
• Open End Bearing: BALL
• Drive End Bearing: BALL
