US MOTORS DH25S2HF ELEVATOR MOTORS
US MOTORS DH25S2HF ELEVATOR MOTORS

U.S. Motors DH25S2HF Submersible Elevator Three Phase ODP Horizontal - Footed Motor

US MOTORS
Brand: US MOTORS
SKU: DH25S2HF
Availability: Out Of Stock
Call for Pricing Call for pricing (215) 326-9845
Call for Pricing Call for pricing (215) 326-9845
LTL Delivery

This product weighs 160 lb each and will be shipped via LTL carrier. A lift gate option will be added free of charge for your convenience.

HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The U.S. Motors DH25S2HF is a submersible elevator motor with a power rating of twenty-five horsepower. It operates at a speed of one thousand eight hundred rpm and is designed for three-phase applications. This motor is suitable for various elevator systems and features a horizontal, footed mount.

  • Twenty-five horsepower
  • Three-phase operation
  • Open drip-proof enclosure

Product Highlights

This motor provides reliable performance for elevator applications in commercial and industrial settings.

Product Information

Standard Information

  • Brand: U.S. Motors
  • MPN: DH25S2HF
Technical Specifications
Full Load Efficiency
89.5 %
Mounting
Horizontal Mount, Horizontal - Footed
Enclosure
ODP, Drip Proof
HP
25
Full Load rpm
1755 rpm
Enclosure Designation
ODP - Open Drip Proof
Open End Bearing
40BC02J3
RPM
1800 rpm
Insulation
F
Service Factor
1
Frame
256T, 256
Duty
Intermediate-Duty
C Dimension
23.1 in
Phase
Three Phase
Poles
4
Full Load Amps
72
Drive End Bearing
40BC02J3
Hz
60 Hz
Motor Application
Elevator, Submersible Elevator
Voltage Rating
200
Weight
160.0 LB
EAN or UPC
786382055837
