U.S. Motors D1CP2PCR General Purpose Single Phase ODP C-Face Motor

Product Description

The U.S. Motors D1CP2PCR is a general purpose single phase motor designed for efficient performance in various applications. This motor features a one horsepower output and operates at a speed of one thousand eight hundred RPM. It is suitable for use in a variety of settings requiring reliable power.

• Voltage rating of 115/230 volts
• Open drip proof (ODP) enclosure design
• Continuous duty operation with a service factor of 1.15

Product Highlights

This motor is ideal for HVAC systems, pumps, and other equipment needing consistent power input.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: D1CP2PCR

Technical Specifications

• Voltage Rating: 115/230
• Enclosure Designation: ODP - Open Drip Proof
• Phase: Single Phase
• Frequency: 60 Hz
• Integrity: ODP
• Insulation: Class B
• Motor Application: General Purpose
• Poles: 4
• C Dimension: 13.1 inches
• Full Load RPM: 1725 RPM
• Service Factor: 1.15
• Frame: 56C
• Weight: 31.43 LB
