TYLOK 081SA400K000030 Solenoid Valve

Product Description

The TYLOK 081SA400K000030 is a solenoid valve from the ASCO Numatics Mark 8 Series. This solenoid pneumatic valve works electrically and features spool and sleeve actuation. The unit has a spring return and flush manual override. It operates as a 2-position 4-way valve, designed for unlubricated or lubricated service. Easy installation is ensured with a plug-in design that allows for electrical connections without disrupting existing piping.

• Electrically-actuated solenoid pneumatic valve.
• Spring return with spool and sleeve actuation.
• Plug-in design for quick replacement.

Product Highlights

This valve is ideal for various pneumatic applications, enhancing efficiency in control systems.

Product Information

Standard Information

• Voltage: 110-120 V AC
• Control Voltage: 110Vac-120Vac (50Hz/60Hz)

Technical Specifications

• Valve Function: 4-Way, 2-Position (5/2)
• Port Size: 1/8 inch NPTF
• Flow Capacity: 37 to 46 SCFM @ 80 PSIG
• Operating Pressure Range: Vacuum to 150 PSIG
• Temperature Range: -10 to +115°F / -23 to +46 °C
• Connection Type: Plug-in with light
• Series: MK8 Series
• Degree of Protection: NEMA 4
