Tweco 1220-1336 Tapered Nozzle 3/8 in Bore 250A Mig

Product Description

The TWECO 1220-1336 is a Weldskill 22 Series tapered MIG welding nozzle rated for light to medium duty applications up to 250 amps. The nozzle features a 3/8 inch (0.375 inch) bore and measures 3.015 inches in length with a 3/4 inch outer diameter. The housing is cut and formed from 122 DHP copper alloy tubing, delivering solid thermal conductivity and corrosion resistance. The part number is rolled and stamped on the outer surface for fast identification in the field. This nozzle is sold as a 2-pack and is installed by MIG welding technicians performing production or maintenance welding tasks.

The 1220-1336 is designed for use with standard gas diffusers in light to medium duty MIG welding setups. It slides over the standard nozzle insulator (Part No. 32, Stock No. 1320-1100) and is adjustable to set the desired contact tip and nozzle relationship. The tip-flush copper alloy construction protects weld quality and extends gun service life. Typical applications include fabrication, maintenance, and repair welding where amperage demands stay at or below 250 amps.

Key Features

• 3/8 inch bore diameter suits standard gas diffusers in 22 Series guns
• Nozzle housing cut and formed from 122 DHP copper alloy tubing for thermal durability
• Adjustable fit allows positioning for the desired contact tip and nozzle relationship
• Part number rolled and stamped on outer surface for easy field identification
• Slides over standard nozzle insulator Part No. 32 (Stock No. 1320-1100)
• Sold as a 2-pack per unit

Compatibility

Designed for use with TWECO Weldskill 22 Series MIG guns and standard gas diffusers. Compatible with standard nozzle insulator Part No. 32 (Stock No. 1320-1100). Rated for light to medium duty welding applications up to 250 amps.

Installation Notes

Installation is performed by a qualified MIG welding technician. Always power down and disconnect the welding machine before replacing consumables. Slide the nozzle over the standard nozzle insulator and adjust axially to achieve the correct contact tip and nozzle relationship before resuming operation. Do not exceed the 250-amp rating for this nozzle.

Technical Specifications

• Series: Weldskill 22
• Nozzle Type: Tapered
• Bore Diameter: 3/8 inch (0.375 inches)
• Nozzle Length: 3.015 inches
• Outer Diameter: 3/4 inch
• Amperage Rating: 250 amps
• Material: 122 DHP Copper Alloy
• Pack Quantity: 2 per pack
• Weight: 0.14 pounds
• UPC: 608246287737

Standard Information

• Brand: TWECO
• Manufacturer Part Number: 1220-1336
