Tweco 1220-1306 Mig Nozzle Slip-on Copper 1/2 Inch 250A

Product Description

The TWECO 1220-1306 is a heavy-duty slip-on copper MIG welding nozzle designed for use with Tweco Spray Master MIG guns rated up to 250 amps. It features a 1/2 inch bore, an overall length of 2.383 inches, and a 0.875 inch outer diameter. The nozzle uses a 3-piece construction: a housing cut and formed from 122 DHP copper alloy tubing, an insert machined from solid brass, and an insulator made from G7 silicone material. The part number is rolled and stamped on the outer surface for fast identification in the field. This nozzle is installed by welding technicians working in high-amperage MIG applications.

This nozzle is suited for heavy-duty MIG welding applications up to 250 amps where longer electrical stick-out is needed or where the nozzle may contact the work surface. The recessed contact tip relationship of 0.125 to 0.156 inches makes it appropriate for tack, spot, and stitch welding. It fits standard gas diffusers. The nozzle insert slides over the metal spring of the gas diffuser, while the G7 silicone insulator provides the electrical isolation required between the nozzle and the diffuser. Sold in a pack of 2.

Key Features

• Slip-on design fits standard gas diffusers on Tweco Spray Master MIG guns up to 250 amps
• 3-piece construction: 122 DHP copper alloy housing, solid brass machined insert, and G7 silicone insulator
• Recessed contact tip relationship of 0.125 to 0.156 inches for longer electrical stick-out or nozzle-to-workpiece contact situations
• Part number rolled and stamped on outer surface for easy identification during service
• No additional insulator required due to integrated 3-piece design
• Sold as 2 per pack

Compatibility

Designed for use with Tweco Spray Master MIG guns rated up to 250 amps and fits standard gas diffusers as specified by the manufacturer.

Installation Notes

Installation is performed by qualified welding technicians. Power down and disconnect the MIG gun from the welding machine before replacing the nozzle. Ensure the nozzle insert is fully seated over the gas diffuser spring before resuming operation. Inspect the silicone insulator for wear or damage during each nozzle change to maintain proper electrical isolation.

Technical Specifications

• Bore Size: 0.5 inches
• Nozzle Length: 2.383 inches
• Outer Diameter: 0.875 inches
• Amperage Rating: 250 amps
• Contact Tip Relationship (Recess): 0.125 to 0.156 inches
• Housing Material: 122 DHP copper alloy
• Insert Material: Solid brass
• Insulator Material: G7 silicone
• Weight: 0.15 pounds
• Quantity per Pack: 2

Standard Information

• Brand: TWECO
• Manufacturer Part Number: 1220-1306
