Tweco 1160-1755 Mig Contact Tip 3/64 Inch

Product Description

The TWECO 1160-1755 is an aluminum MIG contact tip designed for the Velocity2a consumable system. It feeds welding wire at 3/64 inch and transfers welding current to the wire at the point of arc initiation. The tip is engineered with a single set of threads rather than the two or three thread sets common in standard MIG consumables. Mating threads combine brass and stainless steel to reduce seizing and cross-threading. The result is a contact tip that installs without tools and maintains a consistent, reliable electrical contact throughout the weld cycle. Licensed welders and MIG technicians are the primary installers of this consumable.

This contact tip is suited for MIG welding applications where consumable changeover speed and thread reliability are priorities. The Velocity2a system it belongs to offers Fixed Threaded, Adjustable Slip, and Spot Weld nozzle configurations, making this tip compatible with a range of joint access and tack welding scenarios. It is sold individually and is appropriate for light-duty to production welding environments where 3/64 inch wire diameter is specified.

Key Features

• Single-thread design reduces seizing and cross-threading compared to standard two- or three-thread MIG tips
• Brass and stainless steel mating threads combine soft-against-hard contact to prevent thread lockup
• No-tool installation for faster consumable changeover at the gun
• Compatible with Fixed Threaded nozzle for consistent flushness between nozzle opening and tip
• Compatible with Adjustable Slip nozzle for variable flushness and improved cleaning access
• Compatible with Spot Weld nozzle configuration for tack and spot MIG applications

Compatibility

Designed for use with the TWECO Velocity2a MIG gun consumable system. Verify wire diameter and thread pattern against your existing Velocity2a nozzle and diffuser before installation.

Installation Notes

Contact tips are installed and replaced by qualified welders or MIG welding technicians. Before changing the tip, disconnect or power down the welding system and allow the gun and nozzle to cool to a safe handling temperature. Do not overtighten; the brass thread design is intended to seat without excessive torque. Inspect the bore for spatter buildup and replace the tip when the bore is elongated or arc initiation becomes inconsistent.

Technical Specifications

• Wire Diameter: 3/64 inch
• Length: 1.3 inches
• Width: 0.44 inches
• Height: 1.3 inches
• Weight: 0.03 pounds
• Unit of Measure: Each
• UPC: 608246434117

Standard Information

• Brand: TWECO
• Manufacturer Part Number: 1160-1755
