Tweco 1110-1312 Velocity2a Mig Contact Tip 0.045 Inch

Product Description

The TWECO 1110-1312 is a non-threaded, drop-in style MIG welding contact tip designed for the Velocity2a tip system. Machined from solid copper, it delivers a continuous conductor path with minimal connection points, producing a smooth, stable arc and reducing spatter during operation. The centered liner design optimizes wire feedability and electrical surface contact. Rated at 0.045-inch wire diameter, the tip is installed and removed without tools, making nozzle service fast during production welding. Licensed welders and MIG welding technicians working in fabrication, manufacturing, or field welding applications will find the drop-in design significantly reduces downtime.

The 1110-1312 is suited for MIG welding processes using 0.045-inch solid or flux-core wire. The rotatable tip body allows the technician to index the tip to a fresh contact zone, extending service life before replacement is required. This reduces the number of consumable changes per shift and lowers the overall cost of consumable parts. The tip is sold individually and is a direct component of the Velocity2a consumable platform.

Key Features

• Non-threaded drop-in design installs and removes without tools
• Solid copper construction provides a continuous conductor path with fewer connection points
• Optimized electrical surface contact for a smooth, stable arc
• Centered liner design improves wire feedability
• Rotatable tip body extends usable service life per tip
• Reduced spatter output means less post-weld cleanup
• Fewer consumable parts per assembly lowers cost of ownership

Compatibility

Designed for use with the TWECO Velocity2a consumable tip system for MIG welding guns accepting 0.045-inch wire diameter non-threaded contact tips.

Installation Notes

Installation is performed by a qualified welding technician or operator. Power down and de-energize the welding system before servicing the contact tip or nozzle assembly. No threading or tools are required for removal or installation of this drop-in tip. Inspect the liner and nozzle for wear or spatter buildup at each tip change.

Technical Specifications

• Wire Diameter: 0.045 inches
• Tip Style: Non-threaded drop-in
• Material: Solid copper
• Length: 0.74 inches
• Width: 0.35 inches
• Height: 0.35 inches
• Weight: 0.02 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 10
• UPC: 608246431109

Standard Information

• Brand: TWECO
• Manufacturer Part Number: 1110-1312
