Tweco 1110-1310 Mig Contact Tip 0.035 Inch

Product Description

The TWECO 1110-1310 is a Velocity2a non-threaded MIG contact tip designed for 0.035 inch wire diameter. It is machined from solid copper to provide a continuous conductor path with fewer internal connections, which reduces resistance and supports a smooth, stable arc. The drop-in, non-threaded design allows tool-free tip changes directly at the gun, reducing downtime during production welding. A centered liner bore optimizes both electrical surface contact and wire feedability. The tip can also be rotated during service to distribute wear and extend usable life. MIG welding technicians and fabricators working in industrial and manufacturing environments are the primary installers.

The 1110-1310 is suited for MIG welding applications using 0.035 inch solid or flux-cored wire. It fits into compatible TWECO Velocity2a-series MIG gun nozzle assemblies that accept the drop-in contact tip format. Typical use cases include production fabrication, structural welding, and general-purpose MIG work where fast consumable changes and consistent arc performance are priorities. The tip is sold individually (each) with a minimum order quantity of 10 units.

Key Features

• Non-threaded drop-in design allows tool-free contact tip changes
• Solid copper construction provides a continuous low-resistance conductor path
• Centered liner bore optimizes wire feedability and electrical surface contact
• Tip can be rotated to distribute wear and extend service life
• Fewer consumable parts compared to conventional threaded tip assemblies
• Smooth, stable arc with reduced spatter output

Compatibility

Designed for use with TWECO Velocity2a-series MIG gun assemblies that accept the non-threaded drop-in contact tip format and 0.035 inch wire diameter.

Installation Notes

Contact tip replacement is performed by MIG welding technicians. Always power down the welding system and allow the gun to cool before changing consumables. The non-threaded drop-in design requires no tools — remove the nozzle, lift out the worn tip, and seat the replacement. Confirm the tip is fully seated and the nozzle is secured before resuming welding.

Technical Specifications

• Wire Diameter: 0.035 inches
• Tip Design: Non-threaded drop-in
• Material: Solid copper
• Length: 0.74 inches
• Width: 0.35 inches
• Height: 0.35 inches
• Weight: 0.15 pounds
• Sold As: Each
• Minimum Order Quantity: 10
• UPC: 608246431086

Standard Information

• Brand: TWECO
• Manufacturer Part Number: 1110-1310
