Tweco 1110-1308 Mig Contact Tip 0.023 Inch

Product Description

The TWECO 1110-1308 is a Velocity2a series non-threaded MIG contact tip designed for 0.023 inch wire diameter. Built from solid copper, it provides a continuous conductor path with fewer internal connections, which promotes a smooth, stable arc and reduces spatter during welding operations. The drop-in, tool-free design allows fast tip changes without shutting down the wire feeder for extended periods. A centered liner bore optimizes wire feedability and electrical surface contact simultaneously. Welding professionals on MIG and flux-core setups install and rotate these tips to extend service life and reduce consumable replacement frequency.

This contact tip suits light-gauge MIG welding applications where 0.023 inch solid or flux-core wire is used. It is appropriate for production welding, automotive bodywork, sheet metal fabrication, and general repair work. The non-threaded Velocity-style retention system fits compatible TWECO Velocity2a gun nozzle assemblies. Because tips can be rotated before replacement, technicians get more usable life per tip, lowering the cost of consumables on high-cycle welding stations.

Key Features

• Non-threaded drop-in design — no tools required for tip changes
• Solid copper construction provides a continuous conductor path with fewer connections
• Centered liner bore optimizes wire feedability and electrical surface contact
• Tips can be rotated to extend usable service life
• Smooth, stable arc performance with reduced spatter
• Fewer consumable parts per assembly lowers overall cost of ownership

Compatibility

Designed for use with TWECO Velocity2a series MIG gun nozzle assemblies accepting 0.023 inch wire diameter contact tips.

Installation Notes

Contact tips are installed and serviced by welding technicians. Power down the welder and release wire tension before changing the tip. The non-threaded drop-in design requires no tools — align the tip correctly with the Velocity2a retention slot before seating. Inspect the tip bore for wear or spatter buildup regularly and rotate the tip to a fresh wear surface before replacing to maximize tip life.

Technical Specifications

• Wire Diameter: 0.023 inches
• Tip Style: Non-threaded drop-in (Velocity2a)
• Material: Solid copper
• Length: 0.74 inches
• Width: 0.35 inches
• Height: 0.35 inches
• Weight: 0.02 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 10

Standard Information

• Brand: TWECO
• Manufacturer Part Number: 1110-1308
