Tweco 1020-1131 Mig Gun 200A 10 Ft Miller Connection

Product Description

The TWECO 1020-1131 is a Professional No. 2 Series air-cooled MIG gun rated at 200 amps with a 60% duty cycle using CO2 gas. It accommodates wire sizes from 0.040 to 0.045 inches and ships with a 10-foot lead cable featuring a Miller-style rear connection. The oval-shaped handle is balanced to pivot at its center, reducing operator fatigue during extended use. A 60-degree metal jacket conductor tube with full 360-degree swivel capability and a fully insulated Mig-Kwik connection at the wire feeder allow fast front-end changes and quick connect or disconnect at the feeder. Licensed HVAC, welding, and fabrication professionals install this gun in semi-automatic MIG welding setups.

The 1020-1131 is suited for medium fabrication, maintenance and repair, farm and shop environments, and light production work. The 10-foot cable provides good wire feedability without excessive weight. The silver-plated trigger contacts self-clean each time the trigger is engaged or disengaged, extending contact service life. A steel spring strain relief supports the Cablehoz exiting the rear of the handle to reduce wire feed issues, and two ball-point screws lock the Cablehoz and conductor tube securely in place. The gun hanger at the bottom of the handle allows easy resting between passes.

Key Features

• 200-amp rating with 60% duty cycle at CO2 gas
• Accommodates wire sizes 0.040 to 0.045 inches
• 10-foot lead cable with Miller-style rear connection
• 60-degree metal jacket conductor tube with full 360-degree swivel around handle
• Silver-plated trigger contacts with self-cleaning action on every engage and disengage cycle
• Steel spring strain relief and two ball-point screws secure Cablehoz and conductor tube
• Balanced pivot point at handle center reduces operator fatigue; bottom gun hanger for resting

Compatibility

Designed for use with Miller-style wire feeders. Compatible with the TWECO Professional No. 2 Series front-end consumable system. Verify rear connection style matches feeder before installation.

Installation Notes

Installation and service should be performed by a qualified welding equipment technician or trained operator. Disconnect and de-energize the wire feeder and power source before attaching or removing the gun cable. Confirm the Miller-style rear connector seats fully before resuming operation. Follow applicable ANSI, AWS, and equipment manufacturer safety guidelines for MIG welding installations.

Technical Specifications

• Amperage: 200 amps
• Duty Cycle: 60% at CO2 gas
• Wire Size Range: 0.040 to 0.045 inches
• Cable Length: 10 feet
• Cooling Method: Air-cooled
• Conductor Tube Angle: 60 degrees
• Rear Connection Style: Miller style
• Package Weight: 7.85 pounds
• Package Dimensions: 23 inches x 14.5 inches x 3.2 inches
• Sold As: Each
• UPC: 608246012148

Standard Information

• Brand: TWECO
• Manufacturer Part Number: 1020-1131
