Tweco 1020-1115 Mig Gun 200A 25 Ft Air-cooled

Product Description

The TWECO 1020-1115 is a Professional No. 2 Series air-cooled MIG gun rated at 200 amps with a 25-foot lead cable, designed for semi-automatic welding in medium fabrication environments. It accepts wire diameters from 0.030 to 0.035 inches and operates at a 60% duty cycle with CO2 gas. The oval-shaped, crush-resistant handle is balanced to pivot at its center, reducing operator fatigue during extended use. A 60-degree metal jacket conductor tube swivels a full 360 degrees around the handle for repositioning without disconnecting. The silver-plated trigger contacts feature a self-cleaning action each time the trigger is engaged or disengaged. Licensed welding professionals and skilled fabricators are the primary installers and operators of this gun.

This MIG gun is suited for a wide range of applications including shop fabrication, maintenance and repair, farm work, garage use, and light production welding. The 25-foot Tweco-style rear connection cable provides good wire feedability and connects to compatible wire feeders via a fully insulated Mig-Kwik connection for quick attachment and removal at the feeder. A steel spring strain relief supports the Cablehoz exiting the rear of the handle to reduce wire feed issues. Two ball-point screws secure the Cablehoz and conductor tube in place. A gun hanger at the bottom of the handle allows easy resting when the gun is not in use.

Key Features

• 200 amp rating with 60% duty cycle at CO2 gas
• Accepts 0.030 to 0.035 inch wire diameter
• 25-foot lead cable with Tweco-style rear connection and Mig-Kwik feeder interface
• 60-degree metal jacket conductor tube with full 360-degree swivel around handle
• Three-layer conductor tube construction for extended service life
• Oval crush-resistant handle balanced at center pivot to reduce operator fatigue
• Silver-plated trigger contacts with self-cleaning action on each actuation

Compatibility

Designed as an OEM-style replacement and industry-standard MIG gun compatible with wire feeders using Tweco-style rear connections. A feeder adapter plug may be required depending on the wire feeder model.

Installation Notes

Installation and service should be performed by a qualified welding technician familiar with MIG welding equipment. Disconnect and de-energize the wire feeder and welding power source before making or breaking gun connections. Inspect the Mig-Kwik connection and conductor tube seating before returning the gun to service. Follow applicable AWS and equipment manufacturer guidelines for MIG gun replacement and cable routing.

Technical Specifications

• Amperage: 200 amps
• Duty Cycle: 60% with CO2 gas
• Wire Diameter Range: 0.030 to 0.035 inches
• Cable Length: 25 feet
• Cooling Method: Air-cooled
• Conductor Tube Angle: 60 degrees
• Connection Type: Tweco-style rear connection with Mig-Kwik feeder interface
• Package Weight: 13.3 pounds
• Package Length: 23 inches
• Package Width: 14.4 inches
• Package Height: 3.1 inches
• UPC: 608246056326

Standard Information

• Brand: TWECO
• Manufacturer Part Number: 1020-1115
