Truair 170 16X16 Stamped Face Return Air Grille 16 in W x 16 in H 368 to 856 cfm

Product Description

The TRUaire 17016X16 is a one-way stamped face return air grille designed for efficient air distribution. This grille measures sixteen inches in width by sixteen inches in height and has a thickness of one-quarter inch. It is made of durable steel and features a powder-coated finish to enhance longevity. This grille is suitable for use in residential or commercial HVAC systems, allowing for optimal airflow rates between three hundred sixty-eight to eight hundred fifty-six cubic feet per minute (cfm).

• Durable white powder-coated finish
• Suitable for sidewall or ceiling installation
• High airflow capacity for effective ventilation

Product Highlights

This grille combines practicality with a clean aesthetic suitable for various applications.

Product Information

Standard Information

• Brand: TRUaire
• MPN: 17016X16

Technical Specifications

• Blade Spacing: 1/2 in
• Country of Origin: VN
• Deflection Angle: 55 deg
• Material: Steel
• Overall Depth: 1/4 in
• Effective Area: 179 sq-in
• Flow Rate: 368 to 856 cfm
• Package Weight: 3.24 lb
• Package Dimensions: 17.75 in H x 17.75 in W x 0.25 in L
• Finish: Powder Coated
• Series: 170
• Size: 16 in W x 16 in H x 1/4 in THK
• Type: 1-Way
