Tru Audio a.6x 6-zone Home Audio Streaming Amplifier

Product Description

The TRU AUDIO a.6x is a multi-zone home audio streaming amplifier designed for whole-home and light commercial audio distribution. It delivers 50 watts per channel across 12 channels, supporting up to six independent listening zones simultaneously. Each zone can stream a different audio source, making it suitable for custom installations where multiple rooms or areas require independent audio control. Licensed audio installers and custom integration professionals are the primary trade installing this unit. The amplifier accepts both wired and wireless inputs, includes a 7-band parametric EQ per zone, and operates on auto-switching voltage from 115 to 230 VAC.

The a.6x is built for residential whole-home audio systems and light commercial applications such as restaurants, retail spaces, or hospitality environments. Its 6x6x6 architecture allows six different users to stream six different audio sources to six different zones at the same time. Zone control is managed through a mobile app on any smartphone or tablet. The unit accepts six local line-level inputs, two bus line-level inputs, and network streaming inputs, giving integrators flexibility in source configuration. Party zone grouping is also supported for simplified multi-zone playback.

Key Features

• Six independent audio zones with simultaneous playback of different sources
• 50 watts per channel output at 8 or 4 ohms across 12 channels
• Native streaming support compatible with popular music streaming apps via network input
• 7-band parametric EQ with adjustable presets per zone for precise audio tuning
• Six wireless inputs plus one macro party input for flexible source assignment
• Auto-switching operating voltage (115-230 VAC, 60/50 Hz) for domestic and international use
• 2U rack-mount form factor for clean equipment room or rack installation

Compatibility

Designed for integration into residential and light commercial whole-home audio systems where multi-zone distribution and independent zone streaming are required. Compatible with standard 8-ohm and 4-ohm passive speakers.

Installation Notes

Installation should be performed by a licensed audio-video integrator or custom installation professional familiar with multi-zone audio distribution systems. Power down the unit completely before making any speaker or line-level wiring connections. Ensure the rack enclosure provides adequate ventilation clearance around the unit, as power amplifiers generate heat during sustained operation. Consult the manufacturer installation guide for app-based commissioning and zone configuration procedures before powering on.

Technical Specifications

• Zones: 6
• Channels: 12
• Output Power: 50 watts per channel at 8 or 4 ohms
• Wired Inputs: Network, 2 bus line level, 6 local line level
• Wireless Inputs: 6 plus 1 macro party
• Outputs: 2 selectable line level
• EQ: 7-band parametric, adjustable with presets per zone
• S/N Ratio: Greater than 101 dB
• Frequency Response: 5 Hz to 50 kHz
• Operating Voltage: 115-230 VAC, 60/50 Hz auto-switching
• Rack Space: 2U
• Dimensions (without feet): 17 inches W x 3.46 inches H x 14 inches D
• Dimensions (with feet): 17 inches W x 4.7 inches H x 14 inches D
• Shipping Weight: 17.5 pounds

Standard Information

• Brand: TRU AUDIO
• Manufacturer Part Number: a.6x
