TRINE ACCESS TECHNOLOGY 4800F-US32D Electric Strike for Rim Exits Fire Rated 12-24VAC DC

Product Description

The TRINE ACCESS TECHNOLOGY 4800F-US32D is an electric strike designed for surface-mounted rim exit devices. This product has a three-hour fire rating, making it suitable for both new and replacement installations in wood or metal single door frames. It is compatible with voltages ranging from 12 to 24 AC and DC, featuring built-in electronics for surge protection.

• Fire rated with a 3/4 inch strike
• Open cavity provides full 3/4 inch depth and supports a 1 inch throw using provided spacer plates
• Field selectable fail-safe or fail-secure operation

Product Highlights

Made for durability and safety, this strike is ideal for high-traffic areas while ensuring compliance with fire safety standards.

Product Information

Standard Information

• Brand: TRINE ACCESS TECHNOLOGY
• MPN: 4800F-US32D

Technical Specifications

• Category: Access Control, Electric Strikes
• Faceplate Size: 8-1/4 inches x 1-3/4 inches
• Faceplate Style: Round Corner
• Fail Status: Field Selectable
• Finish Color: Satin Stainless Steel
• Frame Type: Metal, Wood
• Grade: Grade 1
• Handing: Non-Handed
• Lock Category: Rim Exits
• Throw: 1 inch, 3/4 inch
• Voltage: 12V DC, 24V DC
