Trerice PTC14401 Tridicator 1/2 NPT Connection 3 Inch Face 30-250F/0-75 PSI/KPA

Product Description

The Trerice PTC14401 Tridicator is designed for monitoring both temperature and pressure in hot water boilers. This Tridicator, with 1/2 inch NPT connection and a 3 inch face, provides reliable measurements from 30 to 250 degrees Fahrenheit and from 0 to 75 PSI/KPA.

• Combines pressure gauge and thermometer
• Easy-to-read dial
• Durable materials for long service life

Product Highlights

This instrument features a compact design, combining a pressure gauge and thermometer into one unit. It's ideal for various industrial applications like chemical processing, HVAC systems, and manufacturing processes, ensuring optimal performance and safety.

Product Information

Standard Information

• Brand: Trerice
• MPN: PTC14401
• Dial Size: 3 inches
• Connection Type: 1/2 inch NPT
• Pressure Range: 0 to 75 PSI/KPA
• Temperature Range: 30 to 250 degrees Fahrenheit

Technical Specifications

• Accuracy: 3% for temperature, 3-2-3% for pressure
• Material: Steel case, bronze tube, brass socket
• Finish: Black
• Mounting: Bottom
• Dimensions: Case width 3.24 inches, case height 1.6 inches
• Standards/Certifications: ASME Boiler code section IV HG-612
• Liquid Filled: No
