Trerice D82LFB2502LA15 D80 Utility Gauge, 0 to 15 psi Pressure, 1/4 in Connection

Product Description

The Trerice D80 Utility Gauge, MPN D82LFB2502LA15, is designed to meet rugged performance demands. This liquid-filled gauge features a stainless steel case and a crimped ring for durability. Wetted parts are constructed from either bronze with a brass socket or stainless steel for reliable operation.

• Pressure range from zero to fifteen psi
• Connection size of one-fourth inch
• Diameter of two and one-half inches for easy readability

Product Highlights

This gauge is suitable for a range of applications requiring precise pressure measurements.

Product Information

Standard Information

• Manufacturer: H.O. Trerice
• Series: D80

Technical Specifications

• Accuracy: +/- 1.6 %
• Connection Size: 1/4 in
• Dial Diameter: 2-1/2 in
• Dimensions: 2.68 in Dia x 1.18 in D
• Graduations: 3
• Liquid Filled: Glycerin
• Material: 304 Stainless Steel
• Mounting Type: Stem
• Pressure Range: 0 to 15 psi
• Temperature Rating: 150 deg F
