Trerice 842615110558 4 in 700 Industrial Pressure Gauge (4 in) 700SS4004LA30/30

Product Description

The Trerice 842615110558 is a Series 700 dry vacuum pressure gauge featuring a 4 in dial and a measurement range of 30 in Hg to 30 psi. The gauge provides +/- 1% accuracy (ASME B40.100 Grade 1A) and uses a 1/2 in stem mount with a lower MNPT connection. Wetted parts are 316 stainless steel; the case is 304 stainless steel with a satin finish and a 250 deg F temperature rating.

• Measurement range 30 in Hg to 30 psi with +/- 1% accuracy (Grade 1A)
• 316 stainless steel tube and socket wetted parts, 304 stainless steel case, satin finish
• 1/2 in stem mount with lower MNPT connection; 4 in dial (3.98 in) and 3.98 in x 2.24 in overall dimensions

Product Highlights

Series 700 dry vacuum pressure gauge, 4 in dial, 30 in Hg to 30 psi range, +/-1% accuracy, 1/2 in stem mount, 316/304 stainless steel construction, 250 deg F rating

Product Information

Standard Information

• Brand: TRERICE
• Manufacturer Part Number: 842615110558
• Country of Origin: USA

Technical Specifications

• Brand: Trerice
• Manufacturer: H.O. Trerice
• Manufacturer Part Number: 700SS4004LA30/30;700SS4004LA030
• UPC: 842615110558
• Series: 700
• Type: Pressure and vacuum measuring
• Application: Industrial
• Accuracy: +/- 1 %
• Pressure Range: 30 in Hg to 30 psi
• Connection Size: 1/2 in
• Connection Location: Lower MNPT
• Mounting Type: Stem mount
• Dial Diameter: 4 in (3.98 in actual)
• Dimensions: 3.98 in diameter x 2.24 in depth
• Wetted Material: 316 stainless steel (tube and socket)
• Case Material: 304 stainless steel
• Finish: Satin
• Graduations: 10/5
• Temperature Rating: 250 deg F
• Ring Type: Bayonet type ring
• Category: Mechanical pressure gauges
• Standards/Approvals: ASME B40.100 Grade 1A; CRN Registered; cULus Listed; NSF/ANSI 372/61; Water Quality MH59892
