Trerice 842615108920 Utility Pressure Gauge 0-30 Psi

Product Description

The TRERICE 842615108920 is a Series 800B utility pressure gauge designed for general-purpose pressure monitoring in mechanical systems. It features a 1-1/2 inch dial diameter with a 0 to 30 psi range and delivers plus or minus 1.6 percent accuracy across 5 graduated increments. The gauge body is drawn steel with a black finish, and the 1/8 inch connection mounts via stem. It carries a temperature rating of 180 degrees F, making it suitable for a broad range of fluid and gas service applications. Licensed plumbers, HVAC technicians, and mechanical contractors install this type of instrument during system commissioning, pressure testing, and ongoing maintenance routines.

This gauge is appropriate for residential and light commercial applications where a compact, low-range pressure instrument is required. The 1-1/2 inch dial fits installations with limited panel or pipe space. Its 1/8 inch NPT stem-mount connection is common on gauge ports across boilers, compressors, water lines, and HVAC equipment. The 0 to 30 psi range suits low-pressure gas, water supply, and hydronic heating monitoring. Manufacturer part numbers 800B1501LA30 and 800B1501LA090 are associated with this gauge configuration.

Key Features

• 0 to 30 psi pressure range with 5 psi graduations for clear, low-range readability
• Plus or minus 1.6 percent accuracy for reliable field readings
• 1-1/2 inch dial diameter in a compact 1.57 inch body diameter
• 1/8 inch stem-mount connection fits standard gauge ports
• Drawn steel case with black finish rated to 180 degrees F
• Made in the USA by H.O. Trerice

Compatibility

Designed as an OEM-style utility pressure gauge for low-pressure mechanical systems requiring a 1/8 inch stem-mount connection and a 0 to 30 psi measurement range. Associated manufacturer part numbers include 800B1501LA30 and 800B1501LA090.

Installation Notes

Installation is typically performed by a licensed plumber, HVAC technician, or mechanical contractor. Isolate and depressurize the system before removing any existing gauge or fitting. Apply appropriate thread sealant to the 1/8 inch NPT connection per local plumbing and mechanical code requirements. Do not overtighten the gauge stem, as this may damage the socket or crack the case.
