Trerice 800B4002LA030 Pressure Gauge Utility 4 in Dial 30 in Hg - 30 psi

Product Description

The Trerice 800B4002LA030 is a utility pressure gauge made from drawn steel. It is designed to indicate pressure for various general applications. This product features a four-inch dial with a measuring range of 30 inches of mercury to 30 psi. It includes a lower mount connection for easy installation.

• Wetted parts made of bronze tube and lead-free brass socket
• Brass movement inside a black finished, stem-mounted flangeless case
• ANSI/NSF certified for safe water use

Product Highlights

Reliable performance and cost-effective for various pressure monitoring needs.

Product Information

Standard Information

• Brand: Trerice
• Manufacturer: H O Trerice

Technical Specifications

• Model: 800B
• Mounting: Lower
• Dial Size: 4 in
• Connection Size: 1/4 in
• Connection Type: MNPT
• Temperature Rating: 180 deg F
• Finish: Black
• Measuring Range: 30 in Hg - 30 psi
• Accuracy: Plus/Minus 1.6% Full Scale
• Diameter: 3.94 in
• Depth: 1.38 in
• Standards/Certifications: ANSI/NSF 61 and 372 certified, cULus MH59892 listed, ASME B40.100
