Product Description
The Trerice 800B2002LA30/30 is a dry utility pressure gauge designed for general pressure indication. This gauge meets various industrial requirements and delivers dependable service. Its wetted parts include a bronze tube and lead-free brass socket.
This gauge has a pressure range from thirty inches of mercury to thirty pounds per square inch. It features a quarter-inch male national pipe thread connection, a two-inch dial diameter, and an accuracy rating of one point six percent. The maximum temperature rating is one hundred eighty degrees Fahrenheit, and it is designed for lower mounting with a steel case.
- Reliable performance in general pressure applications
- Durable steel construction for added longevity
- Compact size that fits various installation spaces
Product Highlights
The Trerice 800B series is recognized for its accuracy and durability in demanding environments.
Product Information
Standard Information
-
Manufacturer: H.O. Trerice
-
Brand: Trerice
Technical Specifications
-
Series: 800B
-
Type: Dry
-
Pressure Range: 30 in Hg to 30 psi
-
Accuracy: 1.6%
-
Connection Size: 1/4 in MNPT
-
Dial Diameter: 2 in
-
Dimensions: 1.97 in Dia x 1.16 in D
-
Material: Steel Case
-
Mounting Type: Lower
-
Temperature Rating: 180 deg F
-
Color: Black
