Trerice 800B1501LA160 800B Dry Utility Pressure Gauge 0 to 160 psi 1/8 in MNPT Connection 1-1/2 in Dia Dial

Product Description

The Trerice 800B1501LA160 is a dry utility pressure gauge designed for general pressure indication needs. This gauge provides reliable performance with a pressure range from zero to 160 psi. It features a one eighth inch MNPT connection and a one and a half inch dial diameter.

The wetted parts of the gauge are constructed of a bronze tube and lead-free brass socket. The gauge operates with an accuracy of one point six percent at a temperature rating of one hundred eighty degrees Fahrenheit.

• Designed for general pressure indication
• Features reliable service with economic value
• Constructed with lead-free materials

Product Highlights

The Trerice utility pressure gauge is ideal for various industrial applications. It is suitable for HVAC systems, plumbing applications, and other uses where pressure measurement is essential.

Product Information

Standard Information

• Brand: Trerice
• Manufacturer: H.O. Trerice

Technical Specifications

• Type: Dry
• Color: Black
• Connection Size: 1/8 in MNPT
• Dial Diameter: 1-1/2 in
• Dimensions: 1.57 in Dia x 1.02 in D
• Material: Steel Case
• Mounting Type: Lower
• Pressure Range: 0 to 160 psi
• Series: 800B
• Temperature Rating: 180 deg F
