Trerice 800B1501LA15 800B Utility Gauge 0 to 15 psi

Product Description

The Trerice 800B Utility Gauge is a mechanical pressure gauge designed to meet general pressure indication requirements. This gauge is built for reliable performance, featuring wetted parts made from bronze tube and lead-free brass socket.

Key specifications include a pressure range of zero to fifteen psi and an accuracy of +/- one point six percent. The gauge has a one eighth inch connection size and a dial with an overall diameter of one and a half inches.

• Suitable for various pressure measurement applications
• Durable design with drawn steel construction
• Stem mounting option for versatile installation

Product Highlights

This gauge is effective for HVAC systems and various plumbing applications. Its construction ensures resistance to corrosion, providing long-lasting service.

Product Information

Standard Information

• Brand: Trerice
• Manufacturer: H.O. Trerice

Technical Specifications

• MPN: 800B1501LA15
• Pressure Range: 0 to 15 psi
• Accuracy: +/- 1.6%
• Connection Size: 1/8 in
• Dial Diameter: 1-1/2 in
• Dimensions: 1.57 in Dia
• Material: Drawn Steel
• Mounting Type: Stem
• Temperature Rating: 180 deg F
• Graduations: 3
• Series: 800B
