Trerice 700SS4002LA60 700 dry industrial pressure gauge 4 in replacement 842615107893

Product Description

Trerice 700SS4002LA60 is a 700 Series dry industrial pressure gauge with a 0 to 60 psi range, 4-inch dial, and 1/4 in MNPT lower mount connection. It has a 304 stainless steel stem-mounted, flangeless case with a satin finish, laminated safety glass lens, micro-adjustable pointer, +/-1% accuracy, and a 250°F temperature rating. The gauge is field liquid-fill capable without a kit and suits industrial process measurement and monitoring.

• 0 to 60 psi range, 4 in dial, 1/4 in MNPT lower mount; overall dimensions 3.98 in diameter x 2.24 in depth
• 304 stainless steel case (satin finish) with laminated safety glass lens, micro-adjustable black pointer, +/-1% accuracy, rated to 250°F
• Dry type with field liquid-fill capability (no kit required); wetted part options include bronze with lead-free brass socket, stainless steel, or Monel

Product Highlights

4 in dial, 0–60 psi range; 1/4 in MNPT lower mount; 304 stainless steel case; +/-1% accuracy; field liquid-fill capable

Product Information

Standard Information

• Brand: TRERICE
• Manufacturer Part Number: 842615107893

Technical Specifications

• Brand: Trerice
• Manufacturer: H.O. Trerice
• Manufacturer Part Number: 700SS4002LA60
• UPC: 842615107893
• Series: 700
• Type: Dry
• Pressure Range: 0 to 60 psi
• Dial Diameter: 4 in
• Connection Size: 1/4 in MNPT
• Mounting Type: Lower (bottom)
• Accuracy: +/- 1 %
• Case Material: 304 stainless steel (stem-mounted flangeless case)
• Wetted Parts Options: Bronze tube with lead-free brass socket; stainless steel tube and socket; Monel tube and socket
• Window Lens: Laminated safety glass
• Pointer: Micro-adjustable black pointer
• Fill Type: Dry (field liquid-fill capable without kit)
• Temperature Rating: 250 deg F
• Dimensions: 3.98 in Dia x 2.24 in D
• Weight: 1.3 lbs
• Finish: Satin
• Application: Industrial process measurement and monitoring
• Standards and Approvals: ASME B40.100 Grade 1A; cULus Water Quality MH59892; CNR Registered
