Trerice 700B4002BA160UCB 4 0-600 PSI Dry Pressure Gauge U-Clamp 1/4 BM

Product Description

The Trerice 700B4002BA160UCB is an industrial pressure gauge designed for various industrial applications. This gauge features a four-inch dial with a measuring range from zero to six hundred PSI. It connects through a one-quarter inch MNPT lower back and offers an accuracy of plus or minus one percent full scale according to ASME standards. The gauge is suitable for use in environments where durability and accuracy are critical.

• Field liquid fillable feature for enhanced performance
• Stainless steel case offers resistance to corrosion
• Designed for easy mounting with U-clamp

Product Highlights

This pressure gauge is built to withstand rigorous conditions while providing precise readings.

Product Information

Standard Information

• Manufacturer: Trerice
• Part Number: 700B4002BA160UCB

Technical Specifications

• Dial Size: 4 inches
• Measuring Range: 0 - 600 PSI
• Accuracy: Plus/Minus 1% Full Scale (ASME Grade 1A)
• Connection: 1/4 inch MNPT U-Clamp Back
• Temperature Rating: 150 degrees Fahrenheit
• Material of Construction: Satin 304 stainless steel case, laminated safety glass lens, brass movement, bronze tube
• Dimensions: 3.98 inches length, 3.98 inches width, 2.24 inches depth
• Industry Standards: ASME B40.100, CRN Approved
