Trerice 500XB4502LA30/60 500X Vacuum Pressure Gauge 30 in Hg to 60 psi 1/4 in Connection

Product Description

The Trerice 500X Vacuum Pressure Gauge, MPN 500XB4502LA30/60, is designed for industrial applications. This gauge is built with a back flanged cast aluminum case and a stainless steel ring for durability. The wetted parts utilize either a bronze tube with lead-free brass socket or stainless steel components, enhancing reliability in various conditions.

• Pressure Range: 30 in Hg to 60 psi
• Accuracy: +/- 0.5%
• Dial Size: 4-1/2 inches

Product Highlights

This pressure gauge offers precise readings and can withstand harsh environments. It features a surface mount design and has a temperature rating of up to 250 degrees Fahrenheit, making it suitable for a wide range of applications.

Product Information

Standard Information

• Brand: Trerice
• MPN: 500XB4502LA30/60

Technical Specifications

• Accuracy: +/- 0.5%
• Color: Black
• Connection Size: 1/4 in
• Dial Diameter: 4-1/2 in
• Dimensions: 5.88 in Dia x 2.06 in D
• Graduations: 10/10
• Material: Cast Aluminum
• Mounting Type: Surface
• Pressure Range: 30 in Hg to 60 psi
• Series: 500X
• Temperature Rating: 250 deg F
• Type: Vacuum
