Trerice 500XB4502LA30/30 500X Vacuum Pressure Gauge 30 in Hg to 30 psi 4-1/2 in Dia Dial

Product Description

The Trerice 500X Vacuum Pressure Gauge with MPN 500XB4502LA30/30 is built for tough applications across many industries. This pressure gauge features a back flanged design with a durable cast aluminum case and stainless steel ring. Its wetted components consist of a bronze tube and lead-free brass socket or stainless steel.

This gauge measures a vacuum range from thirty inches of mercury to thirty pounds per square inch. The connection size is one fourth inch with a four and one half inch diameter dial. It offers an accuracy rating of plus or minus 0.5 percent and graduations of ten over five. It can withstand temperatures up to two hundred fifty degrees Fahrenheit and is designed for surface mounting.

• Back flanged, cast aluminum case
• Stainless steel ring for durability
• Wide application range in various industries

Product Highlights

Ideal for monitoring vacuum levels in heating, ventilation, air conditioning systems, and other applications in need of precise pressure measurement.

Product Information

Standard Information

• Manufacturer: H.O. Trerice
• Brand: Trerice

Technical Specifications

• Type: Vacuum
• Pressure Range: 30 in Hg to 30 psi
• Connection Size: 1/4 in
• Dial Diameter: 4-1/2 in
• Accuracy: +/- 0.5 %
• Graduations: 10/5
• Material: Cast Aluminum
• Mounting Type: Surface
• Dimensions: 5.88 in Dia x 2.06 in D
• Temperature Rating: 250 deg F
• Series: 500X
