Trerice 450SS4504LA300 450 Dry Pressure Gauge 0 to 300 psi 1/2 in MNPT

Product Description

The Trerice 450 Series Process Gauge, MPN 450SS4504LA300, is suitable for the petrochemical and industrial process sectors. This model features a solid front and blow-out back design, ensuring dependability. It includes a fiberglass reinforced polypropylene turret case with a screw ring and offers a field liquid-fill capability without the need for additional kits. The gauge is built to endure harsh industrial environments while ensuring accurate readings. The wetted parts consist of bronze tubing with a brass socket, stainless steel, or Monel, making it resilient and durable.

• Pressure range of 0 to 300 psi.
• 1/2 inch MNPT connection.
• 4-1/2 inch dial diameter, suitable for clear visibility.

Product Highlights

This gauge maintains an accuracy of +/- 0.5% and operates effectively at temperatures up to 250 degrees Fahrenheit.

Product Information

Standard Information

• Manufacturer: H.O. Trerice
• Brand: Trerice

Technical Specifications

• Type: Dry
• Series: 450
• Accuracy: +/- 0.5%
• Connection Size: 1/2 inch MNPT
• Dial Diameter: 4-1/2 inch
• Dimensions: 5.83 inches diameter x 3.25 inches depth
• Material: Fiberglass Reinforced Polypropylene Case
• Mounting Type: Lower
• Pressure Range: 0 to 300 psi
• Temperature Rating: 250 degrees Fahrenheit
