Trerice 450LFSS4504LA100 450 Pressure Gauge, 0 to 100 psi pressure, 1/2 in MNPT Connection

Product Description

The Trerice 450 Series Process Gauge is a device used for measuring pressure in various industrial and petrochemical processes. It features a robust design that includes a fiberglass reinforced polypropylene turret case and a blow-out back for safety. This gauge is capable of liquid filling without requiring additional kits, ensuring operational reliability and performance. The gauge can withstand extreme industrial conditions while delivering precise pressure readings. It uses a combination of materials, including bronze and stainless steel, ensuring durability and accuracy.

• Pressure Range: 0 to 100 psi
• Connection Size: 1/2 in MNPT
• Accuracy Margin: +/- 0.5 %

Product Highlights

Designed for durability in challenging environments, this gauge maintains accuracy and reliability under pressure.

Product Information

Standard Information

• Brand: Trerice
• Manufacturer: H.O. Trerice

Technical Specifications

• Series: 450
• Dial Diameter: 4-1/2 in
• Dimensions: 5.83 in Dia x 3.25 in D
• Liquid Filled: Glycerin
• Material: Fiberglass Reinforced Polypropylene Case
• Mounting Type: Lower
• Temperature Rating: 150 deg F
