Trerice 450B4502LA60 450 Dry Pressure Gauge 0 to 60 psi

Product Description

The Trerice 450B4502LA60 is a dry pressure gauge designed for the petrochemical and industrial process industries. This gauge features a solid front and a blow-out back, ensuring safety and durability. It is made with a fiberglass reinforced polypropylene turret case and has a screwed ring. The gauge can be liquid-filled in the field without the need for a kit, making it versatile for various applications.

The Trerice 450 Series is built to endure harsh environments while providing accurate readings. It offers a pressure range of zero to sixty psi and has an accuracy of plus or minus zero point five percent. This model includes wetted parts made from bronze, brass, stainless steel, or Monel.

• Durable fiberglass reinforced construction
• Field liquid-fill capability
• Temperature rating up to 250 degrees Fahrenheit

Product Highlights

This pressure gauge is suited for a variety of industrial applications, ensuring precision and durability.

Product Information

Standard Information

• Manufacturer: H.O. Trerice
• UPC: Not available

Technical Specifications

• Type: Dry
• Series: 450
• Accuracy: +/- 0.5 %
• Connection Size: 1/4 in MNPT
• Dial Diameter: 4-1/2 in
• Dimensions: 5.83 in Dia x 3.25 in D
• Material: Fiberglass Reinforced Polypropylene Case
• Mounting Type: Lower
• Pressure Range: 0 to 60 psi
• Temperature Rating: 250 deg F
