Trerice 450B4502LA400 450 Dry Pressure Gauge 0 to 400 psi 1/4 in MNPT

Product Description

The Trerice 450B4502LA400 is a dry pressure gauge designed for use in petrochemical and industrial processes. This unit features a solid front and blow-out back design, made from fiberglass reinforced polypropylene. It has a sturdy construction that caters to rugged industrial applications while ensuring precision accuracy. This gauge includes a unique field liquid-fill capability without requiring additional kits. The wetted parts consist of a bronze tube and brass socket, stainless steel, or Monel for durability.

• Pressure range of zero to four hundred psi.
• 1/4 inch MNPT connection.
• 4-1/2 inch dial diameter with +/- 0.5 percent accuracy.

Product Highlights

Ideal for accurate pressure measurement in challenging environments.

Product Information

Standard Information

• Brand: Trerice
• Manufacturer: H.O. Trerice

Technical Specifications

• Type: Dry
• Series: 450
• Accuracy: +/- 0.5 %
• Connection Size: 1/4 in MNPT
• Dial Diameter: 4-1/2 in
• Dimensions: 5.83 in Dia x 3.25 in D
• Material: Fiberglass Reinforced Polypropylene Case
• Mounting Type: Lower
• Pressure Range: 0 to 400 psi
• Temperature Rating: 250 deg F
