Trerice 450B4502LA200 450 Dry Pressure Gauge 0 to 200 psi 1/4 in MNPT

Product Description

The Trerice 450 Series Process Gauge, MPN 450B4502LA200, is tailored for the petrochemical and industrial process sectors. Its robust design features a fiberglass reinforced polypropylene turret case and a solid front with a blow-out back. This gauge offers a field liquid-fill capability, eliminating the need for additional kits. With a pressure range of 0 to 200 psi, it ensures reliability even under extreme industrial conditions. The wetted parts consist of bronze tube/brass socket, stainless steel, or Monel.

• Accuracy of +/- 0.5%
• Temperature rating of 250 degrees Fahrenheit
• Lower mount design

Product Highlights

This gauge is built to meet rigorous accuracy requirements. It is suitable for harsh environments, making it ideal for various industrial applications.

Product Information

Standard Information

• Brand: Trerice
• Manufacturer: H.O. Trerice

Technical Specifications

• Type: Dry
• Series: 450
• Accuracy: +/- 0.5%
• Connection Size: 1/4 in MNPT
• Dial Diameter: 4-1/2 in
• Dimensions: 5.83 in Dia x 3.25 in D
• Material: Fiberglass Reinforced Polypropylene Case
• Mounting Type: Lower
• Pressure Range: 0 to 200 psi
• Temperature Rating: 250 degrees Fahrenheit
