Trane TTA12044DAAE02P Odyssey 10 Ton 1 hp Commercial Air Conditioner Condenser

Product Description

The TRANE TTA12044DAAE02P is an Odyssey 10 Ton 1 hp Commercial Air Conditioner Condenser. It features a comprehensive line of split system components to meet various load and installation requirements. The multi-speed fan and single-zone VAV improve energy efficiency and comfort through superior control with part- and full-load configurations.

• Comprehensive line of split system components to meet various load and installation requirements
• Multi-speed fan, single-zone VAV improve energy efficiency and comfort through superior control with part- and full-load configurations
• New standard Symbio 700 unit controller optimizes performance, improves serviceability, and provides unit connectivity

Product Highlights

This condenser provides easy installation and service with ground-level access and designed-in simplicity.

Product Information

Standard Information

• Brand: TRANE
• Manufacturer Part Number: TTA12044DAAE02P

Technical Specifications

• A2L Compatible: No
• BTU Cooling Rating: 120000 Btu/h
• Coil Type: Micro-channel
• Collection: Odyssey
• Compressor Stages: Two Stage
• Compressor Type: Scroll
• Configuration: Horizontal, Vertical
• Horsepower: 1 hp
• IEER: 14.8
• IEER Range: 14.0 - 99.9
• Liquid Line (OD): 1/2
• Max CFM: 8800
• Max Fuse Size: 50
• Phase: Three Phase
• Refrigerant: R-410A
• Suction Line (OD): 1-1/8
• Tonnage: 10 Ton
• UL Listed: UL 1995
• Volts: 460V
