Trane RLY2586 Relay, 15A SPDT, 24V AC/DC Coil

Product Description

The Trane RLY2586 is an electromechanical relay designed for reliable switching in various applications. It features a single-pole, double-throw (SPDT) contact configuration, making it suitable for HVAC systems, industrial automation, and control mechanisms. Its coil operates at 24V AC/DC and supports a current rating of up to 15A.

• SPDT contact configuration
• 15A current rating
• 24V AC/DC coil voltage

Product Highlights

This relay is UL listed and meets essential standards, ensuring safety and quality for industrial and commercial use.

Product Information

Standard Information

• Brand: Trane
• Manufacturer Part Number: RLY2586

Technical Specifications

• Contact Configuration: SPDT
• Coil Voltage: 24V
• Frequency: 50/60 Hz
• AC Contact Rating: 15A at 125V AC, 1 Hp at 250V AC
• Coil Current: 31 MA at 24V AC, 18 MA at 24V DC
• Coil Input: 24V AC/DC; 50/60 Hz
• Dimensions: 1.25 inches x 4 inches x 1.75 inches
• Operating Time: 6 Msec
• Temperature Rating: -30 to 140 Deg. F
• Mounting Type: Track
• Terminal Type: Screw
• Number of Poles: 1
• Standards: CE, UL
• RoHS: TRUE
• Type: Pilot, Control
• Power Rating: Varies based on AC/DC voltage applied
